SPECIFICATION

CAMERA SPECIFICATIONS

• 1/4” EX-View CCD Sensor
• Optical zoom

DCS-6815: 18X

• Focal length 3.4~61.2 mm
• Angle of view (horizontal): 3.6° ~ 60.8°

DCS-6817: 30X

• Focal length 3.4~102 mm
• Angle of view (horizontal): 2.2° ~ 60.8°

DCS-6818: 36X

• Focal length 3.4~122.4 mm
• Angle of view (horizontal): 1.8° ~ 60.8°
• 12 Digital Zoom
• Day / Night: ICR
• 0.1 Lux (Color); 0.01 Lux (b/W)
• 540 TVL
• Electronic shutter speed 1/1 ~ 1/10K sec
• Auto Gain Control(AGC)
• Manual / Auto Focus(AF)
• Manual / Auto Exposure(AE)
• Manual / Auto While balance(AWb)
• backlight Compensation(bLC)
• Wide Dynamic Range (WDR)

VIDEO CODEC SUPPORT

• JPEG for still image
• MPEG4/MJPEG dual format compression

VIDEO RESOLUTION
NTSC Support:

• up to 30 fps at 176 x 120
• up to 30 fps at 352 x 240
• up to 30 fps at 720 x 480

PAL Support:

• up to 25 fps at 176 x 144
• up to 25 fps at 352 x 288
• up to 25 fps at 720 x 576

VIDEO FEATURES

• Adjustable image size and quality
• Time stamp and text overlays
• Configurable motion detection windows

VIDEO BIT RATE

• up to 3 Mbps

NETWORK PROTOCOL SUPPORT

• IPv4, ARP, TCP/ IP, uDP, ICMP, DHCP
• Client, NTP Client, DNS Client, DDNS
• Client, SMTP Client, FTP Client, HTTP
• Server, PPPoE, uPnP

BUILT-IN NETWORK INTERFACES

• 10/100bASE-TX Ethernet port

LAN

• IEEE 802.3 compliance
• IEEE 802.3u compliance
• Full-Duplex operation
• 802.3x Flow control support for full-duplex mode

IO PORT

• 8 Alarm inputs
• 1 Alarm outputs

DOME OPERATION

• 360° pan capability
• -10° ~ 190° Tilt travel
• 0.225° Pan / Tilt preset accuracy
• 5° ~ 400° Pan / Tilt preset speed
• 4 Cruise presets
• 4 Auto pan presets
• 8 Sequence presets
• 16 Privacy masks
• Auto-flip
• built-in heater and fan
• IP66 standard

SURVEILLANCE SOFTWARE FUNCTIONS

• Remote management/control of up to 32 cameras
• Viewing of up to 32 cameras on one screen
• Management functions provided in web interface
• Scheduled motion triggered, or manual recording

REMOTE MANAGEMENT

• Configuration accessible via web browser
• Take snapshots/video clips and save via web browser

SYSTEM REQuIREMENTS

• Operating System: Microsoft Windows 2000, XP, Vista
• browser: Internet Explorer 6.0 or above

WEIGHT

• 2.6 Kg (5.9 lbs)

POWER INPUT

• AC 24 V

POWER CONSUMPTION

• Max 65 W (with heater)

OPERATING TEMPERATURE

• -40° to 50° C (-40° to 122° F)

STORAGE TEMPERATURE

• -20° to 70° C (-4° to 158° F)

OPERATING HUMIDITY

• 20% to 80% non-condensing

CERTIFICATIONS

• FCC
• CE
• RoHS
