SPECIFICATION

Device Interfaces :

•     10/100 Mbps PoE Lan port
•     802.11n/g/b wireless

LED:

•    Power

Standards :

•     IEEE 802.11 b/g/n
•     IEEE 802.3 u/af

Operation Mode :

• AP
• AP with WDS
• WDS
• Wireless Client.

Wireless Frequency Range :

•     2.4 GHz band: 2.4 GHz to 2.4835 GHz

Antennas :

•     3dBi internal antenna

Maximum Output Power :

•     29.55 dBm

Security  :

•      WPA-Personal
•      WPA-Enterprise
•      WPA2-Personal
•      WPA2-Enterprise
•      WEP 64/128-bit encryption
•      SSID broadcast disable
•      MAC address access control
•      Network Access Protection (NAP)
•      802.1X

SSID/VLAN :

•     Support for up to 8 SSIDs/VLANs

Network Management :

•       Telnet
•      Secure Telnet (SSH)
•      HTTP
•      Secure HTTP (HTTPS)
•      Traffic control
•      SNMP v1,v2 & v3
•      D-Link Central WiFiManager
•      AP Array

Dimensions :

•      105.43 x 228.6 x 35.86 mm

Weight :

•     370.4 grams

Operating Voltage :

•          48 V, 0.5 A or 802.3af PoE compliant

Temperature :

•     Operating: -20 to 60 °C
•     Storage: -20 to 65 °C

Humidity :

•     Operating: 0% to 90% non-condensing
•     Storage: 5% to 95% non-condensing

Certifications :

•     FCC
•     IC
•     CE
•     UL
•     Wi-Fi® Certified
•    IP55
