SPECIFICATION

Computer Connections

• Single KVM:
• 16
• Cascade Chaining:
• Up to 4096

Selection Method

• Switch Button, Hot-Keys (PS/2 Keyboard), and On-Screen-Display (OSD)

LEDs

• Red for PC Selected
• Green for PC On-Line/Ready

PC Connectors

• 16 x HDB-15 female
• Support both PS/2 and USB platform servers

Console Ports

• Keyboard:
• 1 x 6 pin mini-DIN female
• Mouse:
• 1 x 6 pin mini-DIN female
• Video:
• 1 x HDB-15 female
• Firmware Upgrade Port
• Mini USB

Auto-Scan Interval

• 5 - 90 seconds

Video Resolution

• Max. resolution up to 2048 x 1536 @ 65 Hz

Hot-swappable

• Yes

Operating Systems Supported

• Windows 98SE/ME/2000/2003/2008/XP/Vista/7, Linux, Mac OS 9/OS X and Sun Microsystems

Power

• 5V, 2A

Housing Material

• Metal

Operating Temperature

• 32°-122°F (0-50°C)

Humidity

• 0%-80% Relative Humidity

Certifications

• FCC, CE, C-Tick, IC, CSA

Dimensions (L x W x H)

• 17.3 x 6.1 x 1.5 inches (44 x 15.7 x 4.5 cm)

Weight

• 4.2 lbs (1900 g)

Warranty

• 1 Year Limited2

Package Contents

• 16-Port PS2/USB Combo KVM Switch (KVM-450)
• 4 sets of 6ft 4-in-1 PS2/USB KVM cable
• Rack Mount Bracket Kit Set
• Power Adapter
• CD-ROM with Manual and Software
• Quick Install Guide
