20-Port SFP xStack Managed L2+ Stackable switch with 4 Gigabit Combo BASE-T/SFP ports and 2 10G SFP+ ports

DGS-3420-26SC *(This product has been discontinued)

A new generation of switches series xStack DGS-3420 provides networks of large enterprises and small and medium-sized business (SMB) high performance, flexibility, security, and multi-level quality of service (QoS). Switches provide high-density Gigabit Ethernet ports for connecting workplaces equipped with SFP ports and 10 Gigabit SFP + support and advanced features of the software. The switches can be used as a device-level access or aggregation in order to create a multi-level network structure with high-speed backbone and centralized servers connection. Service providers can also take advantage of switches with high port density SFP (eg, DGS-3420-28SC / 26SC) to form aggregation layer optical network (FTTB).

Virtual stack
Native support for Single IP Management technology allows the switch DGS-3420 to become part of a virtual stack and create a multi-level network structure with high-speed backbone and centralized servers connection. In the virtual stack combined devices located anywhere in the same network domain, and used additional uplink ports for 10-Gigabit transmission vnutristekovogo traffic at 20 Gb / s full duplex.

Stacking topology "ring"
Alternatively, the virtual stack, depending on the topology used stacking - linear or failover "ring", users can use one or two ports 10 Gigabit Ethernet SFP +, to create a physical stack. In such a stack 12 can be combined series switches DGS-3420 and have thus to port 576 Gigabit Ethernet.

Security, performance and availability
Switches DGS-3420 series provides a complete set of security features, including multi-level L2 / L3 / L4 Access Control Lists and user authentication (802.1x) via a RADIUS server. To improve the performance and safety switches series DGS-3420 provides support for VLAN, including GVRP and standard 802.1Q. For stable operation of network services and systems such as VoIP and ERP, as well as video conferencing switch supports a wide range of functions QoS / CoS 2/3/4 levels that ensure that critical network services are served in the foreground. To protect the switches against traffic flooding caused by virus / worm series switches DGS-3420 provides features D-Link Safeguard Engine, providing safety, reliability and network availability. Bandwidth control in steps of 64 kbit / s allows you to limit the bandwidth for each port. Bandwidth control allows you to adjust the flows of service types based on specific IP-addresses or protocols.

Support for IPv6
Switches DGS-3420 Series supports IPv6, including a functional and protocols, such as IPv6 Tunnel, ICMPv6, DHCPv6, RIPng, and t. D. Due to 10-Gigabit ports and IPv6 support DGS-3420 series is a cost-effective solution that provides compatibility with the requirements of applicable to IPv6 networks of the future.

Technology D-Link Green
D-Link is a leader in the development of innovative energy-saving technology that does not sacrifice performance or functionality. Switches DGS-3420 series support the technology D-Link Green, which allows the use of power-saving mode, Smart Fan, reduce heat, and automatically reduce power consumption based on cable length. The power saving feature automatically powers down ports. Smart Fan feature automatically turns on the built-in fans at a certain temperature, providing continuous, reliable and eco-friendly operation of the switch.
